I have a pair of Arc Audio ARC10 D4 10" subwoofers. These have a black cone with white logo. Think the SQ of an Image Dynamics IDQ but with more SPL and "umph" //content.invisioncic.com/y282845/emoticons/smile.gif.1ebc41e1811405b213edfc4622c41e27.gif
$120 shipped for the pair
Specs for ONE ARC10 D4:
Impedenence 2 or 8 ohms
Re 3.9 per coil
Fs 25 hz
Qes .365
Qms 5.12
Qts .341
Vas 2.25 cu ft
Xmax 12.3 mm
Sd 350 cm2
Spl 87 dB
Pt 250W RMS
Optimum Sealed .50 cu ft
Small Sealed .30 cu ft
Ported .90 cu ft (net) @ 32 Hz
Displacement .05 cu ft
Cutout 9.25"
Mounting Depth 5.5"
Pictures:
$120 shipped for the pair
Specs for ONE ARC10 D4:
Impedenence 2 or 8 ohms
Re 3.9 per coil
Fs 25 hz
Qes .365
Qms 5.12
Qts .341
Vas 2.25 cu ft
Xmax 12.3 mm
Sd 350 cm2
Spl 87 dB
Pt 250W RMS
Optimum Sealed .50 cu ft
Small Sealed .30 cu ft
Ported .90 cu ft (net) @ 32 Hz
Displacement .05 cu ft
Cutout 9.25"
Mounting Depth 5.5"
Pictures:
