Alpine CDA-9886 w/aux cable and remote

[ALL4SPL 10+ year member]

Item(s) for Sale:

Alpine CDA-9886 with ai-net aux cable, usb extension cable and remote, no trim ring however can be purchased at pacparts.com for $5.

Item(s) Description/Condition:

Shows wear on the main chicklets, the screen has no scratches.

Alpine Electronics of America, Inc.

Price:

$165 shipped USPS priority mail with insurance.

Shipping and Miscellaneous Item Information:

Item Pictures:

(List pictures in this section, 1st picture should be your username/date if you have less than 10 positive feedbacks with the i-Trader system or less than 10 references that you have sold to in the past. (These must be listed in your signature, or a link provided to a feedback thread listing these references)).

Click to read more...



[nutnbutcustm 10+ year member]

This have usb?



[nutnbutcustm 10+ year member]

Just realized the pic with usb,lol.



[tc300 10+ year member]

Does the aux cable have 3.5 jack??? For use with iPod/iPhone/iPad....



[tc300 10+ year member]

Can u show a pic of the back of it plz



[ALL4SPL 10+ year member]

Does the aux cable have 3.5 jack??? For use with iPod/iPhone/iPad....

Yes hold on a few I will snap a picture of the back.



[ALL4SPL 10+ year member]



[tc300 10+ year member]

Man that thing looks super clean..... Not a spec of dirt!!! Lol. Does it have the bass expander X over?



[ALL4SPL 10+ year member]

Full specs;

Features and Specification

SPECIFICATIONS

CEA-2006 Power Ratings

CEA-2006 Power Rating: 4 I? @14.4V Ƈ%THD+N, S/N 80dBA (ref.1W into 4 I?), 18W x 4

Max Power Output Ratings

Max Power Output: 50W x 4

FM Tuner

Tuning Range: 87.7-107.9 MHz

Mono Usable Sensitivity: 9.3dBf (0.8 A?V/75 ohms)

50dB Quieting Sensitivity: 13.5dBf (1.3 A?V/75 ohms)

Alternate Channel Selectivity: 80.0 dB

Signal-to-Noise (S/N) Ratio: 65.0 dB

Stereo Separation: 35.0 dB

Capture Ratio: 2.0 dB

AM Tuner

Tuning Range: 530-1,710kHz

Usable Sensitivity (IEC Standard): 22.5/27.0 (A?V/dBf)

Disc Player

Frequency Response: 5-20k A?1 dB

Channel Separation (at 1kHz): 85dB (at 1kHz)

Dynamic Range (at 1kHz): 95 dB

Total Harmonic Distortion (at 1kHz): 0.008% (at 1kHz)

DAC Type: 24-Bit DSP with integrated DAC

Wow & Flutter (%WRMS): B.M.L.

Oversampling: 8x/352.8kHz

Signal-to-Noise Ratio: 105 dB

Connection for iPodA?

MP3 Decoding: MPEG-1/2 AUDIO Layer-3

WMA Decoding: Windows Media' Audio

AAC Decoding: ACC-LC format ''/m4a'' file

Number of Channels: 2-Channel (Stereo)

Sound Tuning

Subwoofer Level Adjustment: -15dB to 0dB (1dB steps)

Bass Level Control Range: A?14dB at 100Hz

Bass Center Frequency: 60/80/100/200Hz (Selectable)

Bass Band Width Adjustment (Q): 4 choices (1 =narrow, 4 =wide)

Treble Level Control Range: A?14dB at 10kHz

Treble Center Frequency: 10k/12.5k/15k/17.5kHz (Selectable)

MediaXpander Modes: FM, CD, XM, MP3, (Level 1, 2, 3, Off), DVD Video (Level 1, 2, Off), DVD Music (Level 1, Off), (PXA-H100 Required)

MediaXpander Aux Settings: MP3, Music, Movie, (Level 1, Off), (PXA-H100 Required)

Equalizer: 5 Band Parametric (20Hz - 20KHz, 1/3 oct. Steps), 7 Band Graphic, (PXA-H100 Required)

Time Correction: Adjustable 6 Ch. Time Correction (L-F/R-F/L-R/R-R/L-SW/R-SW), (PXA-H100 Required)

Crossover: High Pass: 80/120/160Hz (Selectable)

IMPRINT: IMPRINT Sound System Ready (PXA-H100 Required)

Remote Control

Remote Control: Included

Model Number: RUE-4202

Battery Type: AAA Batteries (2 pcs.)

Dimension (WxHxD) mm : 42mm x 121mm x 23mm

Dimension (WxHxD) in : 1-21/32'' x 4-25/32'' x 29/32''

Weight: 1.5kg (3lbs. 4oz.)

Dimensions

Din Size: 1

Chassis Size (W x H x D) mm: 178mm x 50mm x 160mm

Chassis Size (W x H x D) in: 7'' x 2'' x 6-1/4''

Nose Piece Size (W x H x D) mm: 170mm x 46mm x 24mm

Nose Piece Size (W x H x D) in: 6-3/4'' x 1-13/16'' x 15/16''

General

Power Requirement: Power Requirement: 14.4 (11-16) V.DC

Pre Output Voltage (Before Clipping): 4V

Operating Temperature (A?C/ A?F): 60 A?C (140 A?F) to -10 A?C (14 A?F)

Maximum Mounting Angle: 35A? from Horizontal

Weight: 1.6kg (3lbs 8oz)

FEATURES

Tuner

Memory Presets: Preset Stations (FM:12/AM:6)

Memory: Auto

Seek Mode: Local/DX Selection

HD RadioA?

Built-In or Ready: HD Radio Ready

Connection: Alpine TUA-T500HD Required

Status Indicator: HD Radio Satus Indicator

Signal Switching: Automatic Digital/Analog

Multi-Casting: Multi-Cast HD1, HD2, HD3

BluetoothA?

Parrot Bluetooth Module Built-In: Bluetooth Ready

Connection: Alpine KCE-300BT Required. Features may differ between phone model and service providers.

Hands Free: Hands Free Calling

Phone Book: Phone Book Transfer

Streaming Music: Streaming Music Playback

Streaming Music Control: Streaming Music Control

Connection for iPodA?

Connection Type: Full Speed Connection for iPodA?

Connection for USB: Dedicated iPod Source

Connection: Full Speed Cable Included (KCE-422i)

Compatibility for iPodA?/iPhoneA?: Full Speed Connection: iPhone, 4th/5th Gen. iPod Video/Photo, iPod mini, iPod nano and iPod touch

M.I.X. (Shuffle) Capability: Song, Albums, All

Music Control: Song Up/Down/Repeat

Available Selections: Playlist, Artist, Album, Song, Podcast, Genre, Composer, Audiobook

Percentage Search: Percentage Search

Information Display: Artist, Song, Album

Easy Navigating: Quick Search

Satellite Radio

Built-In or Ready: Satellite Radio Ready

Connection: SIRIUS or XM Adapter Required

Satellite Provider Capability: SIRIUS or XM

Preset Memory: 3-Bands (6 Per Band, 18 Channels Total)

Easy Navigating : Quick Search

Music Information: Category, Artist, Song

Portable Compatibility: SIRIUSPlug N Play Devices (Adapter Required)

Disc Player

Disc Type: CD Player

Disc Playback Type: CD/CD-R/CD-RW

Music Playback: MP3/AAC/WMA Playback

DAC: 24-Bit DSP with integrated DAC

Zero data Mute: 0 Bit Mute

Digital Servo: Digtal Servo

Music Sensor: Scan/Repeat

Playback Control: Play/Pause/Forward/Back

M.I.X. Mode: One (Folder)/All (Random Play)/Random (CD Only)

Easy Navigating: Quick Search

Sound Tuning

Subwoofer Level: Subwoofer Level Adjustment

Equalizer: 5 Band Graphic / 7 Band Parametric Equilizer Ready (PXA-H100 Required)

Bass Level: Bass Level Adjustment

Bass Center Frequency: Bass Center Frequency Adjustment

Bass Bandwidth Adjustment: EQ Width Adjustment

Treble Level: Treble Level Adjustment

Treble Center Frequency: Treble Center Frequency Adjustment

Loudness: Loud Feature

MediaXpander: MediaXpander Ready (PXA-H100 Required)

Time Correction: 6 Channel Time Correction Ready (PXA-H100 Required)

Crossover: High Pass Filter Adjustment

IMPRINT: IMPRINT Sound System Ready (PXA-H100 Required)

CD Changer Control

M.I.X.: One/All (Shuffle)

Multi-Changer Control: Multi-Changer Control including MP3 Changer CHA-S634 (with KCA-410C)

Music Text Information: CD:Text Scroll Display, MP3: Text Information Display (ID3 Tag)

Music Control: Play/Pause/Forward/Back

Repeat: Song/Disc

General

Power Output: 50W x 4 High Power Amplifier

CD Changer: CD Changer Control

Display: 2 Color Biolite Display

Control Type: Rotary Encoder Knob

Face Color: Gunmetal Black

Illumination Buttons: Blue

Playback: MP3/AAC/WMA Playback

Easy Navigating : Quick Search

USB Input: USB (1.1/2.0) Input (Mass Storage Class)

PreOut: 3 PreOut

BluetoothA?: Bluetooth Ready

DAC: 24-Bit DSP with integrated DAC

Auxiliary Input: Versatile-Link Ready (KCA-121B Auxiliary Input)

Steering Wheel Control: Steering Wheel Control Ready

Selectable Power Input: 2 PreIn (Front/Rear)

Bass & Treble: Bass & Treble Controls

Fader & Balance: Fader & Balance Controls

Clock: Built-In Clock

DIN Trim Plate: Detachable Trim Plate

Detachable Face Plate: Detachable Face Plate

Dimmer: Dimmer Input

Power Antenna Lead: Power Antenna Output

Remote Turn-On: Amplifier Remote Turn-On Output

Audio Interrupt: Audio Interrupt Input

Mute: Built-in Audio Mute

Remote Control: Remote Control Included



[SilentAssasin 10+ year member]

yeah but i have an ipod touch 4th gen and it doesnt work on my Alpine cda-9886 same exact cd player, i called alpine they said that no only older ipods work, so no the 4th gen and 5th gen touch DOES NOT work on this cd player! .... im not exactly sure how old your ipod has to be to use on this cd player, but its really pretty shatty if you ask me!..i have a 50 dollar sony in my 2nd truck that i can use any mp3,ipod, cell phone that i want through the AUX or USB, but not on this pricey expensive cd player! ....so i would have to say i like my pos 50 dolla sony way better! even though the alpine looks cool, and of course alpines have the most complicated menus of any cd player out there!



[ALL4SPL 10+ year member]

yeah but i have an ipod touch 4th gen and it doesnt work on my Alpine cda-9886 same exact cd player, i called alpine they said that no only older ipods work, so no the 4th gen and 5th gen touch DOES NOT work on this cd player! .... im not exactly sure how old your ipod has to be to use on this cd player, but its really pretty shatty if you ask me!..i have a 50 dollar sony in my 2nd truck that i can use any mp3,ipod, cell phone that i want through the AUX or USB, but not on this pricey expensive cd player! ....so i would have to say i like my pos 50 dolla sony way better! even though the alpine looks cool, and of course alpines have the most complicated menus of any cd player out there!

Actually using the AUX cable this unit does not control the ipod but will play it, meaning you have to control the ipod itself but it will still play. For FULL ipod control a newer unit would be needed.



[SilentAssasin 10+ year member]

idk bro, me personallyi prefer to use the ipod its self for controll, even this doesnt work on mine, when i called alpine he had me do a hard reboot of the cd player then it worked , next time i got in my truck it didnt, so i did the same reboot still didnt work, i tried about 10 times since then but only worked like 2 times so i gave up on it!...pretty crappy really since its such a **** head unit!

Actually using the AUX cable this unit does not control the ipod but will play it, meaning you have to control the ipod itself but it will still play. For FULL ipod control a newer unit would be needed.



[SilentAssasin 10+ year member]

didnt know Se*y was a bad workd! hhmm

idk bro, me personallyi prefer to use the ipod its self for controll, even this doesnt work on mine, when i called alpine he had me do a hard reboot of the cd player then it worked , next time i got in my truck it didnt, so i did the same reboot still didnt work, i tried about 10 times since then but only worked like 2 times so i gave up on it!...pretty crappy really since its such a **** head unit!



[ALL4SPL 10+ year member]

Well sorry you had bad luck I have ran Alpine for a LONG time, and never had any issues. I only switched to Pioneer since Alpine got out of the High End single din units. They even make a full control cable for this unit for $10 on ebay, however it is limited to certain ipods.



[ALL4SPL 10+ year member]

Sold.
