Item(s) for Sale:
Diamond Audio D5 600.2
Item(s) Description/Condition:
NEW OPEN BOX/Display - This amp was a display piece, has never been installed in a vehicle, comes in original box with original manual.
Price:
$120 + shipping
150W x 2 @ 4 Ohm Stereo
300W x 2 @ 2 Ohm Stereo
600W Bridged @ 4 Ohms (minimum impedance)
Frequency Response: 10 – 50,000 Hz
Signal-to-Noise Ratio: 100dB
THD: 0.03%
Channel Separation: 80dB (min.)
Input Sensitivity: .2 to 5V RMS
Input Impedance: >20k Ohms
Power Supply Operating Range: 11 to 14.5V DC
• Fully Regulated Power Supply
• Up To 5V RMS Input Signal Voltage Capability
• High pass x-over 12 dB/oct. 1.5 kHz-15 kHz Subsonic 15-1.5 kHz
• Adjustable Q with a 10 dB boost
• Low pass x-over 12 dB/oct. stereo 50 Hz-5 kHz, mono 24 dB/oct. 50 Hz-5
kHz
• RCA Outputs
• 2 oz. Silver Plated Copper Circuit Board
• Massive Proprietary Heatsink
Item Pictures:
(List pictures in this section, 1st picture should be your username/date if you have less than 10 positive feedbacks with the i-Trader system or less than 10 references that you have sold to in the past. (These must be listed in your signature, or a link provided to a feedback thread listing these references)).
